Wisycom MCR54-B2 4 Channels Multiband True Diversity Receiver
Wisycom MCR54-B2 4 Channels Multiband True Diversity Receiver
MCR54-B2 — UHF QUAD TRUE-DIVERSITY MINIATURE (CAMERA/BAG) RECEIVER
Range from 470 to 960 MHz, Four Channel Receiver
DSP audio treatment, multicompander. Includes antennas.
NOTE: RX Module only, please order connection kits separatly if not to be used in MRK16 Receiver frame.
MCR54 is a camera quadruple true diversity wireless microphone receiver system in a modular stand alone or slot in configuration. It’s compatible with most camera’s slots and “multi-slot” mixer accessories.
MAIN FEATURES:
Four channels True Diversity receiver (8 Receiver boards!)
Exceptional compactness and high robustness
DSP Analogue & Digital Audio Output (AES3)
Up to 790 MHz bandwidth in 470/1260 MHz range
Next Gen Multiband front-end filtering:
High Q electronically tunable filter in 470-800 MHz
1st narrowband filter
2nd narrowband filter
Wideband and Narrowband DSP-FM operation (SW selectable):
Narrowband allows more 50% band efficiency
Narrowband allows about 3dB extra sensitivity and noise immunity
Extreme low noise VCO with ultrafast spectrum scan for optimal quick & easy setup
High contrast OLED display
Automatic scan & transmitter programming through infrared and Bluetooth 5 long range
DSP based for extreme flexibility and multi-companding operations
Monitor & control through USB C or Bluetooth 5 (long range) on Wisycom Manager 2.0 (computer SW)
Rear antenna connectors and micro audio and power adapter
