Wireless Mic Systems

Lectrosonics Wireless Systems

Lectrosonics SMDWB Miniature Wideband Transmitters

To meet the demand for both extended operating range and extended battery life, the “WB” series SM transmitters offer selectable output power of 25, 50 and 100 mW. With higher power output, the operating range is improved at the expense of battery life. When range is not an issue, a lower power level can be used to extend the battery life.

Key Features:


• Selectable output power to maximize battery life or operating range

• Ultra-lightweight, corrosion resistant housing

• Water resistant seals for use in damp environments

• LCD interface with lockout option

• Programmable compatibility modes for use with a wide variety of different receivers

• Servo Bias input circuitry

• IR (infrared) port for fast setup

• Covers 3 standard frequency blocks

• Update firmware in the field via Micro SD card reader

• Alternate use as recorder on internal microSDHC memory card

Lectrosonics DBSM and DBSMD Digital Transcorders

The DBSM and DBSMD digital transcorders were developed specifically for the needs of the film industry and offer time code jam sync capability. They offer hands free setup and adjustment using audible tones and can be put to sleep to conserve battery power during setup while buried inside costuming, then awakened for normal operation when the production begins. Other features include input gain adjustment in 1 dB increments over a 44 dB range and adjustable low frequency audio roll-off for 3 dB down points at 20, 35, 50, 70, 100, 120 or 150 Hz to control subsonic and very low frequency audio content. The transmitters also offer selectable output power of 10, 25 and 50 mW. A special high-density (HDM) transmit mode at 2 mW allows for ultra-tight channel spacing without concern for frequency coordination.

Key Features:

Encrypted with AES 256 bit CTR, offering four key policies

• RF Power selections at 10, 25 and 50 mW

• Ultra-lightweight, corrosion resistant housing

• OLED interface with lockout option

• Servo Bias input circuitry

• 2-way IR (infrared) port for fast setup

• Alternate use as recorder on internal microSDHC memory card at 48 kHz, 24 bits

• Timecode jam-sync capability with <1ppm accuracy

• High density mode for ultra-tight channel spacing

Lectrosonics HMa Plug-On Transmitter

This unique plug-on transmitter design will ideally match any microphone or line level source via a standard XLR connector. Phantom power is selectable at 5, 15 and 48 volts, or can be turned off for use with dynamic microphones and line level signal sources.

The design includes a wide tuning range of up to 76 MHz, with tuning steps in increments of 100 kHz or 25 kHz for up to 3072 frequencies (19 MHz for block 941 version, for 695 frequencies).

DSP compatibility modes are also included to work with legacy Lectrosonics analog wireless microphone receivers and IFB receivers, as well as some receivers from other manufacturers.

Key Features:

• Accepts microphone or line level signals

• Selectable 5, 15, 48 volt phantom power

• 76 MHz tuning range in 100 kHz or 25 kHz steps for up to 3072 frequencies

• Selectable 50/100 mW output power

• Adjustable low frequency roll-off

• Powered by two AA batteries

• USB port for firmware updates

• IR (infrared) port for fast setup

• Solid machined aluminum housing

Lectrosonics DHu Digital Handheld Transmitter

The DHu Digital Encrypted handheld transmitter represents a versatile solution for a variety of wireless microphone applications including live performance, broadcast, AV rental and houses of worship. The design incorporates advanced features to provide high-quality speech and vocal reinforcement.

Key Features:

• 4th generation digital design

• 256-bit encryption – AES 256-CTR

• Interchangeable thread-on capsules

• Battery powered by two AA batteries

• Selectable RF output power at 25 or 50 mW

• 2-way IR (Infrared) port for fast setup

• 24 bit/48 kHz digital conversion

• Rugged machined aluminum housing

Lectrosonics DCR822 Compact Dual Channel Digital Receiver

The DCR822 compact 2-channel digital receiver with analog and digital audio outputs utilizes the Lectrosonics signature digital architecture with remarkable audio quality and ultra-low latency. The receiver includes an extended operating range rivaling the best analog and Digital Hybrid Wireless® systems with continuously tunable tracking filters covering 470.100 - 614.375 MHz.

Key Features:

• Continuously tunable tracking filters covering 470.100 - 614.375 MHz

• Compatible with D2, Duet and Digital Hybrid Wireless® transmitters

• Vector Diversity with two receivers per channel for superior digital signal recovery

• High IP3 and high-current front ends for robust performance even in severe RF environments

• IR bi-directional port for transmitter setup

• Analog and Digital audio outputs with TalkBack (in applicable RX modes)

• USB interface

• Up to 4 channel recording on microSD card (depending on RX modes)

• AA Battery or external powering

• Same cross-section as the UCR411a for mounting using existing hardware

• Bright, high-density OLED display for clear viewing in any lighting conditions

• AES 256-bit, CTR mode encryption, with 4 different key policies available

Letrosonics DSQD - 4 Channel Digital Receiver

The DSQD Half Rack Receiver with analog and digital audio outputs utilizes the Lectrosonics signature digital architecture with remarkable audio quality and ultra-low latency. The receiver includes an extended operating range rivaling the best analog and Digital Hybrid Wireless® systems with continuously tunable tracking filters covering 470.100 - 614.375 MHz.

Antenna ports on the rear panel accept input from remote antennas, with a “loop-thru” output to another mainframe using the internal multicoupler.

Key Features:

• Four Channel, half-rack design

• Continuously tunable tracking filters covering 470.100 - 614.375 MHz

• Compatible with D2, DSW, Duet and Digital Hybrid Wireless® transmitters

• Built-in wideband antenna multicoupler with loop-thru for additional receivers

• Antenna bias power enabled from the front panel (fused and over-temperature protected)

• IR bi-directional port for transmitter setup

• Analog and Digital audio outputs with TalkBack (in applicable RX modes)

• Ethernet and USB interface

Shure Wireless Systems

Shure AD1 Bodypack Transmitter

AD1 delivers impeccable audio quality and RF performance with wide-tuning, High Density mode, and encryption. Features durable metal construction, optional rechargeable power with dockable charging, and TA4 and LEMO3 connector options.

Key Features:

• Two transmission modes: Standard for optimal coverage and new High Density for maximum system channel count and robust coverage

• Encryption-enabled, secure transmission

• Two connector options: TA4 and LEMO3

• Detachable ¼-wave antenna

• AA or SB900A lithium-ion rechargeable batteries for convenient power options

• External contacts for docked charging

SHURE AD2/SM58 Handheld Wireless Microphone Transmitter

AD2/SM58 delivers impeccable audio quality and RF performance with wide-tuning, High Density mode, and encryption. Features durable metal construction, rechargeable power with dockable charging, and black finish.

Key Features:

• Two transmission modes: Standard for optimal coverage and new High Density for maximum system channel count and robust coverage

• Rugged metal construction in black finish

• Backlit LCD with easy-to-navigate menu and controls

• Low-profile, lockable power switch

• Encryption-enabled, secure transmission

• AA or SB900A lithium-ion rechargeable batteries for convenient power options

• External contacts for docked charging

SHURE Axient AD4D Two Channel Wireless Digital Receiver

The AD4D Two-Channel Digital Receiver sets a new standard in spectral efficiency. Groundbreaking performance features include wide tuning, low latency, and High Density (HD) mode, ensuring solid performance in the most challenging RF environments. Networked control and signal routing options bring a new level of management and flexibility to your entire workflow.

Key Features:

• Wide tuning range up to 184 MHz

• True digital diversity reception per channel for drop-out resistance

• Networked control with Wireless Workbench® software and ShurePlus™ Channels iOS app

• Front panel headphone jack enables Dante™ Cue and Dante™ Browse monitoring

• Configurable Ethernet switch for redundant Dante or AES67 digital output

• AES3 output

• Channel Quality meter displays RF signal-to-noise

• Locking AC connectors

SHURE Axient AD4Q Four Channel Wireless Digital Receiver

The AD4Q Four-Channel Digital Receiver sets a new standard in spectral efficiency. Groundbreaking performance features include wide tuning, low latency, High Density (HD) mode, and Quadversity, ensuring solid performance in the most challenging RF environments. Networked control, AES3 + AES67 + Dante™ output, and signal routing options bring a new level of management and flexibility to your entire workflow.

Key Features:

• Wide tuning range up to 184 MHz

• True digital diversity reception per channel for drop-out resistance

• Networked control with Wireless Workbench® software and ShurePlus™ Channels iOS app

• Quadversity mode for extended antenna coverage and improved RF signal-to-noise

• Front panel headphone jack enables Dante™ Cue and Dante™ Browse monitoring

• Configurable Ethernet switch for redundant Dante or AES67 digital output

• Switchable XLR and AES3 outputs

• Channel Quality meter displays RF signal-to-noise

• Locking AC connectors

Shure axient Ad600 digital spectrum manager

Shure Axient® Digital AD600 Digital Spectrum Manager delivers real-time, wide-band spectrum scanning and monitoring from 174 MHz to 2.0 GHz, spectrum analysis, and frequency coordination in a single rack unit. Six antenna connections deliver multiple coverage options while Dante connectivity provides advanced audio monitoring of your network. Use the USB port to export, import, or save backup scans, event logs, and other important data. The AD600 is an essential addition to your Axient Digital professional audio setup.

Key features

• Advanced, comprehensive RF coordination for your network

• Fast, real-time scanning to find available frequencies and monitor RF activity

• Large, 6.6-inch color display for viewing and analyzing the RF spectrum

• Guided RF coordination to save time and effort in challenging RF environments

• Tools for viewing, analyzing, and listening to RF activity

• Tuning Range: 174 MHz to 2 GHz for support of multiple frequency bands

• (6) antenna connections to support coverage for multiple antennas and zones

• Data capture and storage to archive RF information for analysis

• Network enabled for large-scale system deployments

• USB connections for external data storage of scans, event logs, and other data

• Dante enabled for advanced audio monitoring of your network

• Compatible with Wireless Workbench to extend control and monitoring options

• AC and DC powered options

Shure AD610 Diversity ShowLink® Access Point

The AD610 ShowLink® access point enables real-time remote control of all ShowLink-enabled Axient® transmitters, including both ADX and AXT series models. The access point allows comprehensive management of transmitter parameters from the receiver or Wireless Workbench® using 2.4 GHz (IEEE 802.15.4) wireless communication. All parameter changes occur without interruption to the performer.

Key features

• Wireless network connectivity between all linked transmitters and access points

• Enables real-time wireless remote control of up to 24 transmitters per access point

• ShowLink® offers ability to adjust gain, change frequencies, mute signals, and more

• True Diversity antenna scheme maintains a robust link in the 2.4GHz frequency range

• Automatic channel selection scans the 2.4GHz range for the best channel. Scans can be saved for future analysis in Wireless Workbench

• Automatic frequency agility moves the network to the best available channel if single degrades

• High power option for extended range, accessible via Wireless Workbench (region-dependent)

• Compatible with Axient Digital ADX series and Axient analog systems

MPR52-ENG is a compact two channels receiver designed for professional ENG applications.

The new MPR52 has two built-in diversity receivers with both analog and digital outputs. With up to 790 MHz bandwidth in the 470/1260 MHz range, the MPR52 features next generation multi-band front-end filtering.

KEY FEATURES

• Two channels diversity receiver

• DSP Analogue & Digital Audio Output (AES3)

• NextGen Multiband front-end filtering:
  – High Q moving filter in 470-960 MHz
  – Country-specific saw filters: USA 940-960 MHz

• Wideband and Narrowband DSP-FM operation (SW selectable):
  – Narrowband allows more 50% band efficiency
  – Narrowband allows about 3dB extra sensitivity and noise immunity

• Extreme low noise VCO with ultrafast spectrum scan for optimal quick & easy setup

• A high contrast OLED display

• Automatic scan & transmitter programming through infrared

• DSP based on extreme flexibility and multi companding operations

• Miniature design with an integrated battery pack:
  – rechargeable lithium pack
  – 2 x AA batteries

• Operation and charger (lithium) thru USB connector

• Monitor & control through USB and Wisycom Manager 2.0 (computer SW):
  – This transform MPR52 in a quick and low noise portable spectrum scanner!

RADIO FREQUENCY DISTRIBUTION

WISYCOM™ MAT244 Wideband Programmable Matrix Combiner

MAT244 is very flexible combiner especially designed to manage RF in a multi-site production environment.

MAT244 CAN:
– Route RF in several possible configurations
– Control antenna remotely,
– Manage attenuation/boost for the different areas,
– Monitor RF and interferences thru and integrated RF meter.

All of this can be done remotely thanks to an Ethernet interface and a very intuitive PC software.

MAT244 can be configure locally of by SW as a diversity combiner 4:2 with 6dB gain or in a non-diversity combiner 8:4 / 8:1

KEY FEATURES:

• Combiner mode: diversity 4:2 / non-diversity 8:1 or 8:4 (SW configurable)

• Wide bandwidth 150-840 MHz operation

• Remote management and monitor of alarms thru Ethernet 10/100 base TX

• Antenna booster supply toggled on each input independently

• Voltage and current monitoring on each booster supply with alarm

• Programmable attenuators on each inputs

• Remote boost control (for gain/bandwidth) with a bidirectional data link thru coax (input BNCs)

• light window where the user can enter their own text to identify the 8 areas

WISYCOM™ LFA LDPA Antenna With Amplifier

LFA is a directional antenna with a unique design to achieve an ultra wide band of 410-1300 MHz, a compact and rugged form factor, and ample wind resistance reduction. LFA integrates a unique bank of filters along with a low-noise amplifier. Filters and gain can be easily setup locally through 4-key navigation buttons and a TFT display or remotely with a data connection on the same RF coaxial cable.

Using the latest Wisycom filter technology, LFA gives full control of RF zones and allows you to build flexible and remote controllable antenna systems.

Key Features:

• Huge reception band: 410-1300 MHz

• Remote controllable through coax cable

• RF gain from -12 to +27 dBu (1 dB step)

• Easy configuration through a TFT display

• Tunable filter for interference control

• Antenna off for RF zone disabling

• Fixed band saw filter

• Skeletal design for low wind loading

• 3 High Pass & 3 Low Pass filters

• Waterproof with gasket sealing

WISYCOM™ ADN-ADB Omnidirectional Wideband Antenna

ADN/ADB wideband UHF omnidirectional antenna. Enhances reception providing approx. 3.2 dBi gain.

Key Features:

• Working bandwidth of 430-1160 MHz

• Sturdy metal body construction and epoxy protection on cable joints

• High Performance optimized 3.2dB gain

WISYCOM™ ADFA Wideband Omnidirectional Active Antenna with remote controlled filters

ADFA is an omnidirectional antenna with a unique design to achieve an ultrawideband of 430 -1160 MHz.

ADFA integrate a unique bank of filters along with a low noise amplifier. Filters and gain can be easily setup locally thru a 4 key navigation buttons and a TFT display or remotely with a data connection on the same RF coaxial cable.

Using the latest Wisycom filter technology, ADFA gives a full control of RF zones and allows to build flexible and remote controllable antenna systems.

Key Features:

• Huge reception band: 430-1160 MHz

• Remote controllable thru coax cable (with MAT244/MAT288/SPL2208/SPL2216)

• RF gain from -12 to +27 dBu (1 dB step)

• Easy configuration thru a TFT display

• Tunable filter for interference control

• Antenna off for RF zone disabling

• Fixed band saw filter

• 3 High Pass & 3 Low Pass filters

• Waterproof with gasket sealing

Sennheiser A 5000-CP passive antenna

The A 5000-CP passive antenna provides an optimum solution for both transmitting and receiving RF signals throughout the UHF spectrum.

The wideband design (450-960MHz) of the A 5000-CP allows it to accommodate antenna distribution systems for either wireless monitors or wireless microphones across multiple frequency ranges, offering maximum flexibility when designing complex RF systems.

Key Features:

• High Gain

• Minimized Multipath - minimizes variations in signa strength, almost eliminating multipath problems.

• Broadband

UHF / IN-EAR MONITORING

Synthesized UHF Belt-Pack IFB-R1a Receiver

Wireless IFB (interruptible fold back) systems are used for talent cueing and crew communications in broadcast and motion picture production. In other cases, the IFB system is used by directors and other management to monitor program audio during a production. The IFB R1a receiver provides simplicity and flexibility in a package that is intuitive for untrained users to operate.

The receiver is housed in a rugged machined aluminum package. An optional spring-loaded belt clip (shown at right) provides a secure mounting on a wide variety of belts, pockets and fabrics. The belt clip is removable to reduce its size and allow mounting into other types of bags and belt worn mounting systems common in field production.

Key Features:

• Preset frequency can be set without power or transmitter signal

• Scan mode stores up to five additional frequencies

• Multi-color LED and rotary control for programming and operation

• High sensitivity for extended operating range indoors or outdoors

• Rugged machined aluminum housing

• Attached battery door

• 8 hours battery life (alkaline)

• 20 hours battery life (lithium)

• 256 frequencies in 100 kHz increments

• Microprocessor controlled

• Pilot tone squelch

• Compandor noise reduction

Frequency-Agile Compact IFBT4 Transmitter

The Lectrosonics IFBT4 UHF transmitter was designed for use in broadcast, motion picture, theater, and stage applications where extended operating range and high-quality audio are essential. The IFBT4 can be used as a stand-alone device or patched directly into popular intercom systems.

Lectrosonics Digital Hybrid Wireless™ systems overcome channel noise in a dramatically new way, digitally encoding the audio in the transmitter and decoding it in the receiver, yet still sending the encoded information via an analog FM wireless link. This proprietary algorithm is not a digital implementation of an analog compandor, but a technique that can be accomplished only in the digital domain, even though the inputs and outputs are analog.

Because it uses an analog FM link, Digital Hybrid Wireless™ enjoys all the benefits of conventional FM wireless systems, such as excellent range, efficient use of RF spectrum, and resistance to interference. However, unlike conventional FM systems, it does away with the analog compandor and its artifacts.

Microprocessor control provides user-friendly operation and eliminates transients at turn-on and turn-off. The transmitter output is muted in the TUNE mode to avoid generating interference in other wireless systems while scrolling up and down to change frequencies.

Key FEATURES:

• Digital Hybrid Wireless™ technology

• Up to 256 UHF frequencies in 100kHz steps

• Microprocessor controlled operation

• 250 mW power output for long range use (50 mW for export versions)

• Pilot tone squelch control

• Multi-use XLR input jack

• Built-in microphone preamp

• DIP switch programmable intercom input

• Tx mute for frequency scrolling

• Multi-function LCD display

• Compact size for use anywhere

• Rugged machined aluminum construction

MPR50-IEM Wideband Receiver

MPR50 is a compact true diversity receiver designed for professional in-ear monitoring applications, featuring a real TRUE DIVERSITY configuration along with a unique wide-band tuning range up to 232 MHz.

The output audio stage is especially design to have maximum audio peak-dynamic of 200 mWatt.

Key FEATURES:

• Up to 232 MHz bandwidth in 470/798 MHz range

• TRUE DIVERSITY RECEIVER with 2 whip antennas

• 200 mW peak audio power

• Separate release/attack compander

• Miniature design with 2 AA battery pack integrated (body-pack form factor) or rechargeable lithium pack

• Easy to use thanks to an OLED display

• Dedicated function buttons & frequency scan function

• Automatic receiver programming thru infrared and micro-USB

• FM Stereo mode for MPX decoding with mix-mode function

• FM IFB mode with NARROW-BAND modulation to enhance noise immunity and coverage (SW selectable)

• Flexible Battery management
  -2 AA NiMH or Alkaline
  -C3-V3 battery pack
  -KLIC 8000 or CR-V3R lithium (i.e. DR9708 Duracell)
  -Charge with dedicated charger or integrated micro-usb-B connector.

MTK 952 Wideband Dual Transmitter

MTK952 is a versatile dual transmitter capable of working in a huge UHF bandwidth and of generating any kind of narrow-band modulations, with very high quality and low spurious emissions.

Options:

DC: DC power supply (10-16VDC)

MS: Master Slave configuration for iso-frequency network

Key FEATURES:

• 330 MHz Bandwidth

• Direct Digital Synthesis (DDS) of signal for the highest flexibility and quality (> 70 dB stereo separation)

• Stereo, mono, intercom audio modulation

• DSP audio processing (40bit floating point / 2Gflops) with multi-companding

• Low interference output stage with wideband intermodulation phase cancellation

• 2400 user-defined frequencies (40 group by 60 freq.)

• Analogue & digital input (AES3)

• Output power up to 2 Watt (-2W0 option)

• Redundant power supply 230/110 Vac & 12 VDC (DC is optional)

• SWR (Stationary Wave Ratio) sensing on antenna outputs

• Reference In/Out for iso-frequency transmission (with option MS)

back to top

VHF / IN-EAR MONITORS

Phonak Invisity Flex In-Ear Receiver

The Phonak Invisity Flex In-Ear is designed for film, stage, television production or any situation where discreet, hidden communication is required.

The Invisity Flex is a single frequency, programmable, narrow-band RF receiver. Programmable frequencies fall within a 7mHz band with a choice of 6 ranges.

A rotating switch built into the housing of the Invisity Flex allows on/off and (2) volume settings. It’s ergonomic design ensures greater comfort for longer wear periods.

Battery life is estimated at 13 hours of continuous use.

 back to top

Listen Tech Stationary RF Transmitter LT-800-216-01

Offering outstanding audio clarity, digital signal strength, and 57 selectable channels, the LT-800-216 is a perfect RF transmitter choice for a wide range of applications. Connected to your main audio system, the LT-800-216 broadcasts strong, reliable audio to both belt pack receivers and stationary receivers, ideal for providing listeners with the best possible assistive listening experience.

Key Features:

• Look & Listen (TM) LCD display for quick channel, programming, and channel lock status information

• Balanced and unbalanced audio inputs allow for use with any audio source

• Built-in auto processor optimizes audio (voice or music) prior to transmission

• 57 available, selectable channels

• VU level meter and test tone for simple installation and set up

VX-4/3Z VHF TRANSMIT ANTENNA COMBINER [3 ZONES, 4 INPUTS] (i-code: 102152)

Combines the input of up to four VHF RF IFB or Intercom transmits into a single output antenna.
